Controllable pitch propellers explained

Often found on yachts, controllable pitch propellers (CPPs) offer a huge range of benefits that set them apart from fixed pitch propellers (FPPs).

In this guide, we’ll look at what a controllable pitch propeller is and how to use one. Plus their advantages and disadvantages, and when it’s the right choice for your yacht.

What is a controllable pitch propeller?

A controllable pitch propeller is a type of propeller where the angle of the blades, known as the blade pitch, can be adjusted while the propeller is in motion. This is in contrast to fixed-pitch propellers, where the blade pitch is set to a permanent position.

A CPP typically features:

• A hub
• Propeller blades
• Shafting
• Hydraulics
• Control system

There can also be the choice to add bespoke options to your propeller depending on your requirements.

How do you use a controllable pitch propeller?

Using a controllable pitch propeller involves changing the blade pitch to control thrust and direction instead of altering engine speed or rotation. This is usually controlled from the bridge of a yacht using specific pitch control levers.

For example, a positive pitch will be needed to move forwards while a negative pitch will be required to move backwards. No pitch is needed when the yacht is idling. This control can be particularly useful when manoeuvring in small spaces or stopping the vessel.

Advantages of controllable pitch propellers

Controllable pitch propellers come with a range of benefits that can make them a more favourable option than fixed pitch propellers. Some of the main advantages of CPPs include:

Better manoeuvrability

CPPs allow for better manoeuvrability as thrust can be changed instantly by altering the blade pitch. This is ideal when docking in a tight marina or harbour, or moving around small areas. Controllable pitch propellers enable you to switch quickly between forward and reverse without changing engine rotation, creating a streamlined experience for yacht owners.

Reverse thrust

Controllable pitch propellers can produce reverse thrust by simply adjusting blade pitch with no need to reverse the engine. This enables rapid stopping and precise speed control, both of which are beneficial in yachting.

Improved fuel efficiency

When using a CPP, blade pitch can be optimised for different speeds and load sizes, keeping the engine at its most efficient RPM and contributing to significant fuel savings over time.

Reduced stress on the engine

As a controllable pitch propeller does the work when it comes to making adjustments, the engine doesn’t need to constantly change RPM. This can reduce mechanical stress and maintenance needs, saving yacht owners time, money, and hassle.

Disadvantages of controllable pitch propellers

Controllable pitch propellers have some great advantages, but they do come with some disadvantages too. These include:

High cost

CPPs are more expensive to buy and install than fixed pitch options, which can be a disadvantage if you’re on a budget. They can also cost more over their lifetime as their servicing and maintenance needs are higher.

More mechanical parts

As controllable pitch propellers have more mechanical parts than fixed propellers, more features could break or require maintenance. Failure of CPP parts could result in a loss of thrust, so regular servicing and inspection by professionals is required, which can come at a cost.

Weight

Due to their many mechanical parts, controllable pitch propellers are heavier than fixed pitch propellers, and this can negatively impact fuel consumption. However, CPPs typically boast better fuel economy than fixed propellers overall, so this may not be a cause for concern for many yacht owners.

More complex to use

Controllable pitch propellers are harder to use than fixed blade options as they’re more technical in design. This could mean that training is required before you feel confident using one. Problems with CPPs are also more difficult to identify, which can be an issue for people with limited experience, especially if you run into problems while out on the water.

Main differences between CPPs and FPPs

Several differences between CPPs and FPPs are worth considering.

• Blade pitch adjustment – The blade pitch is permanently set for an FPP, whereas the blade pitch of a CPP can be adjusted during operation via electric mechanisms.
• Thrust control – A CPP allows for thrust variation by changing blade pitch at a constant RPM, and this would require changing the engine speed when using an FPP. A CPP also enables reverse thrust without the need for a reversing engine or gearbox, unlike an FPP.
• Maintenance requirements – CPPs require more maintenance due to their numerous moving parts, whereas the simple design of FPPs means they need very little maintenance. These maintenance requirements can become expensive over time, especially when paired with regular servicing by a professional.
• Cost – Controllable pitch propellers cost more to buy and install than fixed options. They’re also more expensive to service, maintain, and fix, so it can be a costly option over time.
• Fuel efficiency – CPPs boast high fuel efficiency across variable speeds, while FPPs are less efficient unless they’re being used within their optimum range.
• Flexibility – CPPs are far more flexible than FPPs as they can be easily adapted to suit sailing conditions.

Are controllable pitch propellers a good choice for yachts?

Controllable pitch propellers can be a good choice for yachts, but whether they’re the right option for you depends on the type of yacht you have, its intended use, and whether you prioritise performance, cost, or simplicity.

Essentially, if you’re looking for a propeller that offers excellent manoeuvrability and unrivalled efficiency, and you often sail long distances, a CPP could be the perfect option for your yacht. However, if you prioritise affordability, simplicity, and low maintenance, or your yacht runs at mostly constant speeds, an FPP may be the right choice.
